4 Port GEPON L3 OLT Without PON Module

4 Port GEPON L3 OLT Without PON Module

40710 INR/Unit

Product Details:

  • Product Type 4 Port GEPON L3 OLT Without PON Module
  • Dimension(L*W*H) 442 x 200 x 43 Millimeter (mm)
  • Weight 3.2 Kilograms (kg)
  • Click to view more
X

Price And Quantity

  • 40710 INR/Unit
  • 1 Unit

Product Specifications

  • 3.2 Kilograms (kg)
  • 442 x 200 x 43 Millimeter (mm)
  • 4 Port GEPON L3 OLT Without PON Module

Product Description

4 Port GEPON L3 OLT Without PON Module is 1U height 19 rack mount device. The features of this type of module are compact, flexible, easy to deploy, convenient, and high performance. It is ideal to be installed in small room environment. It can also be utilized for Triple-Play, IP Camera, VPN, and Enterprise LAN applications. Moreover, 4 Port GEPON L3 OLT Without PON Module is checked by expert quality controllers to guarantee constant performance, high efficiency, low maintenance need, and cost-effectiveness.

Specifications:

AC Power Supply

AC: 90- 264 V, 47/63 Hz

Number Of Ports/Pins

4

Model Name/Number

OP100P4

Broadcasting Media

FTTH

Brand

Optronix

Weight

3.2 Kg

Working Temperature

0 - +50 C

Wavelength

TX 1490nm, RX 1310nm

Transmission Distance

20 Km

TX Power

+2-+7 dBm (PX20+)

Storage Temperature

-40 - +85 C

Saturation Optical Power

-6dBm

Rx Sensitivity

-30dB (PX20+)

Relative Humidity

5-90% (non-conditioning)

PON Port Connector

SC/UPC

Max Power Consumption

30 W

Management Ports

1 x 10/100 BASE-T out-band port, 1 x CONSOLE port

Fiber Type

9/125 micron m SMF

EPON port speed

Upstream 1.25G, Downstream 1.25G

EPON Port Qty

4

EPON Port Physical Interface

SFP Slot

EPON Port Max splitting ratio

1:64

EPON Port Connector Type

PX20+

Dimension

442 x 200 x 43 mm

Chipset

Broadcom

Chassis Rack

1U 19" standard box

Chassis Qty

8

Functional Characteristics:

Satisfactory Standard:

  • Meet ITU-T G984/G.988 standards

Support IPv6 Function

  • Support DN, IPv6 Ping, IPv6 Telnet
  • Support ACL based on source IPv6 address, destination IPv6 address, L4 port, protocol type, etc.
  • Support MLD v1/v2 snooping

IP route

  • Support static route, dynamic route RIP v1/v2, OSPF v2

Easy to manage

  • Friendly EMS/Web/Telnet/CLI/SSH management
  • CLI command style similar to mainstream manufacturers

Fully open platform

  • Open to any brand of ONU

High performance cost

  • 1U height compact design
  • Adopt mainstream chip scheme
