OP821GWV-D xPON ONU Router

OP821GWV-D xPON ONU Router

Product Details:


Product Description

OP821GWV-D xPON ONU Router is best-in-class high-end networking solution for up-to-date triple play services. This device is compliant with ITU-T G.984 standard, double band wireless for united connection speeds of up to 1200 Mbps (867 Mbps on 5GHz and 300 Mbps on 2.4 GHz), Layer 2/3, and the best quality VoIP as well, OP821GWV-D ONU support the comprehensive triple-play services, comprising video (IPTV or VoD), voice, and high-speed internet access service. OP821GWV-D xPON ONU Router is great for varies organizations and comes in varied models.


Antenna Type

4 external antennas

Model Name/Number


Operational Temperature

0 to 45 Degree C,rel. humidity 10-90% (non-condensing)



Wi-Fi enabled



0.25 Kg

WIFI Interface

IEEE 802.11 ac/n/g/b wireless LAN

Storage Temperature

-20 to 70 Deg C, rel. humidity 10-90% (non-condensing)



Power Consumption

Less than equal to 8W

Power Adaptor

Input: 100 to 240 V AC, 50/60 Hz; Output: 12 V, 1A

POTS Interface

1 FXS Port

Launch power

Min: 0dBm, Max: +5dBm

Interface standard

ITU-T G.984.2/ITU-T G.984.3/ITU-TG.988 Class B+

Input Power Overload

-8 dBm

GPON Interface Rate

Upstream: 1.244Gbps, Downstream: 2.488Gbps

GPON Interface

1 GPON Port


180mm x 120mm x 31mm (L x W x H)

Data Interface

1GE+1 FE


  • Support IPV6, PPPoE, DHCP & Static IP Configuration for WAN Interface
  • IP MAC filtering, firewall functionality in routed mode
  • TR069, NAT, DMZ, DNS Feature
  • Multiple VLAN, SSID
